Triple Band Low Power Digital Repeater

Triple Band Low Power Digital Repeater

Channel Selective Cellular Repeater (CSCR) software-defined repeater is an intelligent solution for boosting and repeating of cellular signals.

  • Supports 900MHz & 1800MHz & 2100MHz frequency bands
  • Bidirectional digital Channel selection
  • Supporting Multi Sub-Bands, Band selective, channel selective, Band tunable
  • Supporting Multi operators and Multi technologies (2G, 3G and 4G)
  • High isolation out of band rejection
  • Tunable bandwidth, 200kHz up to 20MHz
  • 30dBm linear output power at downlink
  • Compact size, easy maintenance and installation (wall-mount)
  • IP65 enclosure (dust-proof and moisture-proof)
  • Local control and monitoring by RS232 port
  • NMS (Network Monitoring System) software to remotely supervise and control the repeater by Built-in modem (SMS).

Download File (You must Authenticate to Download)

Channel Selective Cellular Repeater (CSCR) software-defined repeater is an intelligent solution for boosting and repeating of cellular signals. Precise, sharp and narrowband Digital filters, which is considered as the main advantage of the system for providing bidirectional repeating for single and multi-operator coverage in three cellular bands (900, 1800 and 2100MHz), with SDF technology.

A built-in modem helps the user to monitor and control the system remotely. A GUI software is
also provided to configure and monitor the system locally (RS232) and remotely
